Cutting machine BCA BISONTE TSC470 230V 1.85 KW maximum cutting height 47 cm

Disponibil: in stock

16.610 00 Lei

Cantitate

20.488 00 Lei

Beneficii

Specialized technical consulting
14-day return policy
Quality guarantee
Professional equipment
FREE SHIPPING! PAY ON DELIVERY!

AAC Cutting Machine – precise cuts on site, with reduced dust and noise

General Description

This AAC cutting machine is designed for the construction industry and comes equipped with a ready-to-use blade. It is easy to use on most construction sites in Europe, being suitable for cutting aerated concrete blocks.

It performs precise straight cuts and cross cuts, and with the supplied graduated square, angled cuts between 0° and 90° can be made. The AAC block is moved towards the blade by manual advancement, by pushing the table, for good cutting control.

Cutting is done dry, without water, and due to the low blade speed, noise and dust levels are very low. In addition, the machine has an automatic blade stop system, and the blade only operates during the cutting phases.

Key Benefits

Precise straight and cross cuts for AAC blocks.
Ability to make angled cuts between 0° and 90° with the included graduated square.
Dry cutting, without water, suitable for construction sites.
Very low noise and dust due to low blade speed.
Manual control of feed by pushing the work table.
Automatic stop: the blade only operates during cutting phases.
Tilting work table to reduce dimensions.

Features and Specifications

Feature	Detail
Purpose	Construction industry; cutting aerated concrete blocks (AAC)
Blade	Included, ready to use
Cutting Type	Straight and cross, precise
Angled cuts	0° – 90° (with supplied graduated square)
Operating mode	Dry, without water
Noise and dust	Very low (low blade speed)
Material feed	Manual, by pushing the table
Safety/Operation	Automatic stop system; blade only operates during cutting phases
Work table	Tilting to reduce dimensions
Accessories	Square for diagonal cuts
Optional	Dust extraction system

How to use the product

Place the AAC block on the work table and fix the cutting position.
Set the desired angle with the graduated square (for angled cuts between 0° and 90°) or use the square for diagonal cuts.
Manually advance the table, pushing the block towards the blade; the blade will only operate during cutting phases due to the automatic stop system.

Order now this AAC cutting machine and enjoy precise cuts with reduced noise and dust on site.

Maximum cutting width 420 mm

Maximum cutting length 660 mm

Maximum cutting height 470 mm

Disc diameter 4170 mm

Motor type Electric

Voltage 230 / 50 V / Hz

Engine power 1.85 kW

Adjustable table 0-90 °

Wheel dimensions Ø 200 mm

Noise level (at 7 m.) 74 dB (A)

Equipment weight 185 kg
