Imer Waste Chute System Set 8 Chute Sections 1 Hopper Support and 1 Loading Hopper
- After placing the order, we will confirm the shipping cost via email, which will be calculated based on your location.
IMER Construction Waste Chute System – Set for Small/Medium Jobs, Durability, and Safe Installation
General Description
The IMER construction waste chute system is an advantageous set designed for small and medium-sized jobs, useful for quickly organizing waste disposal on a construction site.
The set includes 8 chute tubes, 1 hopper support, and 1 loading hopper, offering a complete solution for forming and feeding a disposal column.
The tubes are made of premium polypropylene, ensuring exceptional durability and a long service life in all weather conditions. Vertical ribs increase elasticity, absorb shocks, and contribute to internal noise reduction.
Key Benefits
- Complete waste disposal set, ideal for small/medium jobs
- Tubes made of high-quality polypropylene, with high resistance
- Vertical ribs for elasticity, shock absorption, and internal noise reduction
- Hopper support made of galvanized steel, with an adjustable frame
- Clear installation rule: support every 10 m of column height
- Generous hopper dimensions for easy loading
- Components in yellow, with good visibility on site
Features and Specifications
| Feature | Detail |
|---|---|
| Product | IMER Construction Waste Chute System |
| Recommended use | Small / medium jobs |
| Set contents | 8 chute tubes + 1 hopper support + 1 loading hopper |
| Support installation | A loading hopper support is required every 10 m of column height |
| Support role | Supports the subsequent tubes in the column using chains |
Hopper Support (TE0001121) – 1 pc.
| Feature | Detail |
|---|---|
| Product code | TE0001121 |
| Purpose | Loading hopper support |
| Material | Galvanized steel |
| Construction | Adjustable frame |
| Width | 720 mm |
| Height | 650 mm |
| Length | 1050 mm |
| Weight | 13 kg |
Waste Chute Tube (TE0001119) – 8 pcs.
| Feature | Detail |
|---|---|
| Product code | TE0001119 |
| Material | Premium polypropylene |
| Upper outer diameter | 590 mm |
| Upper inner diameter | 500 mm |
| Lower inner diameter | 380 mm |
| Length | 1060 mm |
| Color | Yellow |
| Weight | 8 kg |
Loading Hopper (TE0001120) – 1 pc.
| Feature | Detail |
|---|---|
| Product code | TE0001120 |
| Loading mouth size | 830 × 430 mm |
| Lower inner diameter | 390 mm |
| Height | 650 mm |
| Length | 980 mm |
| Width | 740 mm |
| Color | Yellow |
| Weight | 7 kg |
How to Use the Product
- Assemble the chute tubes to form the column needed for waste disposal on the construction site.
- Install the loading hopper support and position the hopper for easy feeding of the column.
- For tall columns, install a loading hopper support every 10 m and support the subsequent tubes using chains.
Order now the IMER construction waste chute system and enjoy high durability and safe installation on your construction site.
